San Maker Machine Vsi Sand Crusher

Minimum Order Quantity: Negotiate Price Negotiate
Packaging Details Standard container, spare parts will be packed in wooden cases Delivery Time 2 months
Payment Terms: T/T, L/C Supply Ability 50 sets per Month
Place of Origin: Shanghai, China Brand Name: SANME
Certification: ISO&CE Model Number: VC726, VC730, VC733, VC743, VC766, VC788, VC799

Detail Information

Capacity(t/h): 60-1804 Power: 110-2*630KW
Max Feedding Size: 100mm Warranty: One Year
Video Outgoing-inspection: Provided Applicable Industries: Energy & Mining

Product Description

Introduction

VSI sand making machine is a high-performance sand making equipment. It is a perfect combinationof unique rotor structure design, wear-resistant material technology, crushing speed optimization and hydraulic design. It is a model of the perfect combination of professional fine crushing technology and mechanical manufacturing, and is a full embodiment of new technologies and new processes.
This machine is specially designed for the production of high-quality gravel aggregate for expressway, high-speed railway, high-rise building, municipal engineering, hydropower dam construction and concrete mixing plant. It is the first choice in the field of artificial sand making and stone shaping.
Application field:
Expressway, high-speed railway, high-rise building, municipal engineering, hydropower dam construction,concrete mixing plant,etc.
Suitable Material:
River pebble, granite, basalt, iron ore, limestone, calcite, quartz, diabase, etc.

Technical Data of VSI Series Vertical Shaft Impact Crusher:

Model Max Feed Size (mm) Rotor Speed (r/min) Throughput (t/h) Motor Power (kw) Overall Dimensions (L×W×H) (mm) Weight (kg)
VSI3000 45(70) 1700-2000 30-60 75-90 3080×1757×2126 ≤5555
VSI4000 55(70) 1400-1620 50-90 110-150 4100×1930×2166 ≤7020
VSI5000 65(80) 1330-1530 80-150 180-264 4300×2215×2427 ≤11650
VSI6000 70(80) 1200-1400 120-250 264-320 5300×2728×2773 ≤15100
VSI7000 70(80) 1000-1200 180-350 320-400 5300×2728×2863 ≤17090
VSI8000 80(150) 1000-1100 250-380 400-440 6000×3000×3420 ≤23450
VSI9000 80(150) 1000-1100 380-600 440-630 6000×3022×3425 ≤23980
