Road Concrete 900t/H PLC Crawler Mobile Screening Plant

Minimum Order Quantity: Negotiate Price Negotiate
Packaging Details Standard container, spare parts will be packed in wooden cases Delivery Time 2 months
Payment Terms: T/T, L/C Supply Ability 50 sets per Month
Place of Origin: Shanghai, China Brand Name: SANME
Certification: ISO&CE Model Number: MP-S151, MP-S153, MP-S181,

Detail Information

Warranty: 1 Year Type: Mobile Vibrating Stone Screen
Application: Screening For Various Quarries And Building Demolition Waste, Mining Operations And So On. Capacity: 20-900t/h
Max Feeding Size: 10mm-100mm Core Components: PLC, Engine, Bearing, Motor, Gear, Pump
High Light:

PLC Crawler Mobile Screening Plant,900t/H Mobile Screening Plant,110kw Mobile Screening Plant

Product Description

Mobile screening station is a kind of high efficiency screening equipment, which adopts crawler driving mode, advanced technology and complete functions. Because of its unique optimized dynamic design and intelligent process control system, it has strong and durable, stable and reliable high-efficiency screening ability, which is an ideal choice in many independent screening or multi-stage mobile crushing and screening process.



1. It is widely used in various crushing and screening processes;

2. Screening of materials in quarries and mining areas and screening of aggregates in crushed asphalt and concrete mixing stations;

3. Solid waste resources utilization, such as house demolition, road concrete recycling material screening;

4. Material screening in other industries.


Technical Data of MP-S Series Mobile Screen Plants:

MP-S Series Mobile Screen Plants MP-S151 MP-S153 MP-S181
Screen box(mm×mm) 1500×4500 1500×6100 1800×4800
Deck 2 or 3 2 or 3 2 or 3
Driving Unit
Engine Cummins or CAT Cummins or CAT Cummins or CAT
Performance(kw) 110 138 110
Feed Hopper
Hopper Volume(m3) 10 10 10
Belt Feeder
Drive hydraulic hydraulic hydraulic
Main Conveyor belt
Belt Width(mm) 1200 1200 1200
Drive hydraulic hydraulic hydraulic
Crawler Unit
Drive hydraulic hydraulic hydraulic
Dimensions and Weight
Working Dimensions
-Length (mm) 16457 19800 16539
-Width (mm) 14282 17800 14327
-Height (mm) 4199 7300 4238
Transport Dimensions
– Length (mm) 14840 19500 15130
– Width (mm) 2861 3300 3245
– Height (mm) 3461 3500 3574
Weight (t) 26 39 29


Road Concrete 900t/H PLC Crawler Mobile Screening Plant 0Road Concrete 900t/H PLC Crawler Mobile Screening Plant 1
