HC Series Impact Crusher Machine Long Working Life 50-1200t/H High Capacity

Minimum Order Quantity: Negotiate Price Negotiate
Packaging Details Standard container, spare parts will be packed in wooden cases Delivery Time 2 months
Payment Terms: T/T, L/C Supply Ability 50 sets per Month
Place of Origin: Shanghai, China Brand Name: SANME
Certification: ISO&CE Model Number: HC128, HC139, HC239, HC255, HC579, HC679, HC779, HC798, HC898, HC8118

Detail Information

Application: Mining, Metallurgy, Construction, Highway, Railroad, Water Conservancy, Etc. Condition: New
Capacity(t/h): 50-1200t/h Spare Parts Supply: Will Supply Any Time
Power(w): 37-2000kw Max Feeding Size: 300mm-1600mm
High Light:

impact rock crusher,impact stone crusher

Product Description

HC Series Impact Crusher Machine Long Working Life 50-1200t/H High Capacity

Product Introduction

Unique structure, Energy-efficient . Impact crusher adopts quality steels and wear-resistant parts, which makes it superior and reliable. This machine is possess of rotor with large inertia, and its capacity is improved largely. Impact crusher is usually used as secondary crusher in the production line Applications: Ore crushing, railway, highway, energy, cement, chemical industry, construction, etc.

HC Series Impact Crushers are built on advanced technology with a combination of domestic applications. The overall structure is simple, practical and reasonable.

Features and technology advantages of HC Series Impact Crushers:

1. High-quality plates and wear parts to reduce abrade and improve the production efficiency of various conditions; advanced processing technology is the basis of equipment performance.

2. Strong product commonality can reduce cost. Two-cavity impact crusher can becomes three-cavity machine by adding grinding racks, and no need to change other parts.

3. Heavy type rotor, finite element endurance analysis, optimized design, reasonable structure and enhancing moment of inertia lead to bigger crushing ratio and better abrasion resistance.

4. Static and dynamic balancing test for the welding rotor should be done before assembling. To make sure the rotor has a smoothly running and long working life.

5. Main shaft is finished by quality forging, adopts keyless design and world advanced cover tightening connection to ensure the reliable working and make the maintenance easier.

6. Unique locking device for hammers makes the tightening moment of force more safe and bigger. And the replacement of hammers can be more simple and convenient.

7. Standard design for liners increase the interchangeability, decrease the repertory and variety of liners.

8. Simple but practical locking device lock the shell 1 and shell 2 together. This device has a easy operation and saves locking time.

9. Unique hydraulic device design is convenient for opening the fame racks to replace wear parts and adjust the discharge size.

10. Simple structure for impact racks and grinding racks. Easy operation, long working life, convenient maintenance and low cost

Technical Data of HC Series Impact Crushers:

Model Max Feed Size(mm) Throughput(t/h) Motor Power(kw) Overall Dimension(L×W×H)(mm)
( the biggest size )
Weight(Motor not included)(t)
HC128 300 40-70 37-55 3115*1600*2932 11.8
HC139 500 50-80 55-75 3060*2048*2935 14.6
HC239 500 100-180 110-132 3095*2048*2970 14.7
HC255 500 100-290 132-160 3095*2398*2970 17.4
HC359Ⅱ 700 180-350 200-250 3415*2666*3127 22.2
HC459 750 220-450 250-315 3717*3020*3301 27
HC579 800 250-550 400-500 3552*3547*3231 36.2
HC679 1000 400-700 560-630 4019*4064*3652 53.2
HC779 1300 500-850 630-800 4785*4338*4849 79
HC798 1300 750-1100 800-1250 4825*4838*4849 90.8
HC898 1500 1000-1500 1000-1600 5382*5445*5454 112.8
HC8118 1600 1400-1900 1400-2000 5382*5945*5454 135.5

HC Series Impact Crusher MachineLong Working Life50-1200t/H High Capacity 0

HC series impact crusher machine.pdf
